Hik Micro Cheetah Night Vision Front Clip-On
The Cheetah is a front-mounted digital night vision add-on that allows you to convert your conventional optical scope into a high-performance night vision riflescope. The Cheetah provides the perfect solution for shooters who want to maintain the uncompromising daytime performance of their optical scopes and then quickly convert to night vision for vermin control.
The Cheetah is capable of outstanding nighttime performance, drawing on all of HIKMICROs expertise in sensor technology and software design. The inbuilt IR delivers up to 400m of detection range in total darkness and delivers a crisp image to the HD OLED display.
The supplied adaptor clamps to the objective bell of your optical scope you create a stable and repeatable mounting point to quickly attach and remove the Cheetah unit.
Specifications
| Model | C32F-R | C32F-RL |
| Max Resolution | 2560 x 1440 | 2560 x 1440 |
| IR Illuminator Wavelength | 850nm | 850nm |
| Lens (Focal Length) | 32 mm, F1.2 | 32 mm, F1.2 |
| Min. Focusing Range | 3m | 3m |
| Detection Range | 400m (with IR 850nm ON) | 400m (with IR 850nm ON) |
| Field of View | 9.9° × 7.5°/17.3m x 13.1m @100m | 9.9° × 7.5°/17.3m x 13.1m @100m |
| Magnification | 1x | 1x |
| Image Display | ||
| Display | 1920 x 1080, 0.49-inch OLED | 1920 x 1080, 0.49-inch OLED |
| Palettes | Day, Night, Green, Yellow, Auto, Defog | Day, Night, Green, Yellow, Auto, Defog |
| Exit Pupil | 22mm | 22mm |
| Eye Relief | 10mm | 10mm |
| Frame Frequency | 25Hz | 25Hz |
| General | ||
| Storage | Built-in EMMC (64 GB) | Built-in EMMC (64 GB) |
| Protection Level | IP67 | IP67 |
| Max Recoil | 1000g/0.4ms | 1000g/0.4ms |
| Dimensions | 182.8mm x 70mm x 87.2mm (7.2 × 2.76× 3.43 inch) | 182.8mm x 70mm x 87.2mm (7.2 × 2.76× 3.43 inch) |
| Weight | ≤465 g without Eyepiece and Batteries | ≤477 g without Eyepiece and Batteries |
| Features | ||
| Ballistic Calculation | No | Yes (When Switching to Scope Version) |
| Hotspot | Yes | Yes |
| Standy Mode | Yes | Yes |
| Record Video | On-board Video Recording (1920 x 1440) | On-board Video Recording (1920 x 1440) |
| Picture in Picture | No | No |
| Capture Snapshot | Yes | Yes |
| Recoil-Activation Recording | Yes | Yes |
| Power Supply | ||
| Battery Type | One Replaceable and Rechargeable Li-ion battery | One Replaceable and Rechargeable Li-ion battery |
| Battery Operating Time | ≥5.5h (@25°C, with Hotspot, IR Emitter off) | ≥5.5h (@25°C, with Hotspot, IR Emitter off) |
| Working Temperature/Humidty | -30°C to 55°C (-22°F to 131°F) | -30°C to 55°C (-22°F to 131°F) |
***Night vision Scopes cannot be delivered to Republic of Ireland if they are to be mounted to a Firearm without relevant Restricted Firearms Certificate and can only be purchased to be used as a standalone handheld device due to Irish Night vision laws***
